Theoretical foundations on how MILP is outlined and how its alternative room appears like visually
This post is a continuation of the sequence (preceding post) on the concept and purposes of Blended Integer Linear Programming (MILP). Right now, we appear at
- the official, basic definition of MILP,
- how its area of feasible solutions appears like.
The to start with component describes how MILP types look in normal, what are and are not legitimate MILP expressions. The 2nd part shows a minor bit of concept behind MILP, which will be practical in the foreseeable future posts when we will be chatting about the precise algorithm for resolving MILP.
This is very a extended article, so seize a coffee and dive in!
In the pursuing textual content, I will use upper-situation daring letters (e.g., A, E) for matrices and lessen-case daring letters for vectors (e.g., x, y). MILP is an optimisation dilemma that can be formulated in matrix notation as follows
Lets crack this monster down. We are presented a problem instance represented by matrices and vectors A, E, b, f, c, d from various domains (ℝ stands for a set of genuine numbers and ℤ for a set of integer numbers). For instance, if we return to our budget problem from the initially submit, the issue occasion signifies belongings, their fees, approximated earnings and also the spending plan. We say that integer vector x and continuous vector y are a possible solution to the specified difficulty occasion, if the adhering to conditions holds
By writing these conditions ingredient-intelligent, we get
exactly where 𝒂ᵢ are the rows of matrix A and 𝒆ᵢ are the rows of matrix E. These inequalities are referred to as constraints.
In MILP, we are searching for a feasible option x, y which minimises the goal functionality
If these kinds of a solution exists, we phone it an ideal option. In scenario you are wanting to know, it is probable to maximise the aim functionality alternatively just multiply it with -1 and minimise the resulting expression. There is no warranty that a feasible option (enable alone optimum) exists, but allows defer the discussion about these situations to the afterwards area.
Despite the fact that the matrix sort is a canonical way how MILP troubles are described, model designers generally do not use it as it is incredibly cumbersome. As a substitute, in apply we outline constraints and aim features using simple mathematical expressions, which will be transformed internally by the solver to the matrix sort (which is actually really helpful for a equipment). To get a experience what is correct MILP formulation and what is not, in this article is a record of a handful of examples:
- 𝑎₁𝑥₁ + 𝑎₂ + 𝑥₃ ≥ 𝑏₁ + 𝑎₄𝑥₄ is a proper MILP constraint. See that in comparison to the canonical sort, the inequality is reversed, a continuous is integrated in the remaining hand side and I added a variable to the ideal hand side. In a canonical kind, this constraint would be remodeled to −𝑎₁𝑥₁ − 𝑥₃ + 𝑎₄𝑥₄ ≤ −𝑏₁ + 𝑎₂ .
- 𝑥₁𝑥₂ is not a proper MILP expression as it is a multiplication of two variables, which is not a linear expression. The same goes for |𝑥₁|, max(𝑥₁, 𝑥₂), log(𝑥₁), etcetera. All of these expressions are not linear, while some of them can be linearised through different tricks, but far more on that in a further submit.
- 𝑎₁𝑎₂ is a accurate MILP expression as multiplying two mounted parameters together would final result in a one mounted parameter in “compile” time, i.e., all through making the matrix design but before setting up the solver. Expressions wherever mounted parameters are remodeled by a mathematical features (these types of as logarithm) are also suitable MILP expressions.
- 𝑎ₓ is not a suitable MILP expression. We cannot use a variable as an index.
- 𝑎₁𝑥₁ < 𝑏₁ is not a correct MILP constraint, it is not possible to force strict inequality.
We finish this section by showing a MILP formulation of the budget problem from the previous post in a matrix form.
The objective uses the multiplication by -1 trick to maximise the expected profit. The budget constraint is encoded in the first row of the constraint matrix and the remaining rows correspond to constraints 0 ≤ 𝑥ᵢ, 𝑥ᵢ ≤ 1 on each variable 𝑥ᵢ (i.e., 𝑥ᵢ is required to be binary). Many solvers allow to specify the domain of the variables directly, so usually there is no need create such constraints by hand. Also, notice that our model includes only integer variables (there is no y variable), thus it is an integer linear program.
When we know how the space of feasible solutions of MILP models looks like, we may start to reason about the general algorithm for MILP, its theoretical properties and possibly how to make more performant models.
Lets start with the following MILP model. For simplicity, we will consider only two integer variables 𝑥₁, 𝑥₂.
How can we visualise this model graphically? We start by empty 2D graph representing a model with no constraint. Gradually, we add constraint by constraint until we have a full model. In the graph, the horizontal and vertical axes correspond to values of 𝑥₁ and 𝑥₂, respectively.
As there is currently no constraint in the model, every combination of 𝑥₁, 𝑥₂ is a feasible solution. Lets add a first constraint 4𝑥₁ ≥ 2𝑥₂ and see what happens. First, draw a line 4𝑥₁ = 2𝑥₂ in the solution space.
This line is a boundary between two half-spaces defined by the following inequalities: 4𝑥₁> 2𝑥₂ and 4𝑥₁ < 2𝑥₂. All the points on one side of the line satisfy inequality 4𝑥₁> 2𝑥₂ and all the factors on the other aspect of line satisfy inequality 4𝑥₁ < 2𝑥₂. When I want to know which half-space represents a specific constraint, I will pick some random point 𝑥₁, 𝑥₂ that does not lie on the line, substitute it into the constraint, and check whether the constraint is satisfied. If yes, then the half-space containing this point is the one that corresponds to the constraint. If not, then the other half-space is the correct one.
So as an example, lets pick point 𝑥₁ = 5, 𝑥₂ = 3. Substitute the values into constraint
and we see that the constraint is satisfied. Therefore, the half-space containing this point is the one where all the points satisfy this constraint. In the graphs I will denote the half-space satisfying a constraint by an arrow. Of course, the points on the line also satisfy the constraint so a constraint is represented by both a boundary line and a half-space.
Lets add another constraint −2𝑥₁ + 30 ≥ 2𝑥₂. Again, we start by drawing a boundary line −2𝑥₁ + 30 = 2𝑥₂.
Which half-space satisfies this constraint? For this test, we pick a point 𝑥₁ = 14, 𝑥₂= 6 and substitute it into the constraint
We see that the selected point does not satisfy the constraint −2𝑥₁ + 30 ≥ 2𝑥₂ so the feasible half-space must be the other one then the one containing point 𝑥₁ = 14, 𝑥₂= 6 .
However, now as we have two constraints in the model, the feasible solution space is an intersection of the feasible half-spaces of each constraint. The reason is that we want all the constraints to be satisfied so only the solutions that lie in all feasible half-spaces are also feasible in the whole model.
Now it should be clear how to proceed with constraints 𝑥₂ ≥ 0, 0.5𝑥₁ + 3.75 ≥ 𝑥₂, so I will just draw the new feasible solution space.
There is one thing left and that is the integrality constraint 𝑥₁, 𝑥₂ ∈ ℤ that we silently ignored at the beginning. What does this constraint mean? Simply, not all points from the coloured region are actually feasible, but only those where both 𝑥₁, 𝑥₂ are integers. We can visualise them by a grid, thus, the final feasible solution space of the example MILP model looks like this.
Each of those red points correspond to one feasible integer solution which satisfy all the constraints. Now, the last question is: which of those points optimise our objective function, i.e., which point gives us the smallest value of −2𝑥₁ − 3𝑥₂? This question is little bit more involved. We could extend our graph to a third dimension representing the values of the objective function, project the feasible solutions to a plane of our objective function and find the projected point that is the lowest. However, I think that it is a nice mental exercise to stay in 2D space and find the optimum there.
Many of you are probably familiar with the concept of a gradient, as it is a backbone of many ML training algorithms. In short, a gradient of a function represents a direction of the largest increase of that function at some point. That is, if we move along the gradient, we will increase the function. Knowing the gradient of the MILP’s objective function tells us where to look for the optimal feasible solution. So, lets find the gradient of our objective function, which we obtain by taking the partial derivatives by each variable 𝑥₁, 𝑥₂
Since our objective function is linear, its gradient is the same for every point in the solution space. And since gradient is a direction, we can draw a vector into our solution space to show the direction of the increase in the objective function.
Lets draw a contour lines of the objective (a contour line has the same objective value for every point on that line). It can be proven that contour lines are perpendicular to a gradient, so once we have the gradient, it is easy to draw the contours. As we move in the opposite direction of the gradient, the objective value on the contour lines decreases until we cannot move any further as we would be outside of the feasible space. You can imagine this process as moving a ruler, which is perpendicular to the gradient, along the direction opposite to the gradient until you touch the last feasible solution. In our example, the optimal solution is at 𝑥₁ = 8, 𝑥₂ = 7 with the objective value of −37. Phew!
If you are intersted in how to write this MILP model in Python, here is the code.
Solver status: OptimizationStatus.OPTIMAL
Optimal objective value: -37
Optimal solution: x1=8, x2=7
In the example above, we found an optimal solution. However, this is not always guaranteed. In theory, the optimisation might end up with one of the following three outcomes: optimal solution found, infeasible model, or unbounded objective.
Other outcomes are also possible (e.g., time-limit reached, out-of-memory, etc.) but they are related to practise, not theory of integer programming so I will not discuss them in this post.
Optimisation outcome: optimal solution found
We already saw a couple of examples where we found an optimal solution (e.g., budget problem). I would like to highlight that there might be multiple optimal solutions with the same objective value. For example, if we replace the objective in the above defined model by 10𝑥₂, then all the points lying on line x₂ = 0 in the feasible solution space are optimal with objective value of 0. Multiple runs of the optimisation solver with various random seeds will probably give different optimal solutions, so do not expect an unique solution to be returned all the time.
Optimisation outcome: infeasible model
Infeasible models are the ones for which there is no feasible solution that would satisfy all the constraints. An example of an infeasible model is the following.
There is no value of 𝑥₁ which would satisfy both 𝑥₁ ≥ 6 and 𝑥₁ ≤ 2, so the intersection of the feasible half-spaces of these constraints is an empty set.
Optimisation outcome: unbounded objective
This one is a little bit weird, but unfortunately, it may occur. Usually in practise, it is a sign of an ill-defined model, e.g., when an essential constraint is not included in a model.
Unbounded objective means that for every feasible solution, we can find another feasible solution having a smaller objective value. In other words, the optimal objective value converges to negative infinity. Here is a model with an unbounded objective.
The feasible solution space is so unconstrained, that we increase 𝑥₂ to any value we want and in turn the objective will decrease.
Right now, you should be able to solve any MILP model with two integer variables using just pen, paper and a ruler! Of course, the actual computer algorithms for solving MILPs are more complicated, but the visual understanding of the solution space will come handy when we study the algorithms in some future post.
